HCS-215F

HCS-215F  2x15“+1,4“ 3-Way Fullrange Speaker

HCS-215F High power 3-way fullrange speaker

“Ready for a life time on the road” HCS-215F is a high power 3-way full range speaker with 1800W AES power. It is developed uncompromisingly for tough use in the touring and rental business. The two 15 " bass chassis deliver a powerful and punchy sub and have a power consumption of 800W AES each.. The Oversized compression driver has a 1.4 "mouth opening and a massive 3" voice coil. With a line uptake of 200W AES this will hardly come to the limits. The HCS-215F convinces on a its high technical level as well as in a convincing price / performance ratio.

HCS-215F GS1 (EAN) CODE: 4260318510912

Technical Details

Model Name HCS-215F
GS1 (EAN) CODE 4260318510912
System Type 3-Way 2x15“+1,4“ Fullrange Speaker
Power Rating 1800 W AES
3600 W program
7200 W peak
Frequency Range (+/- 3 dB) 43 Hz - 20 kHz
Coverage Pattern (hxv) 90°x45°
Sensitivity 103 dB 1w/1m
Maximum SPL 139 dB
Woofer 2 x STG-15FR 800W AES, 3“ voice coil
Driver 1 x STG-75F 200W AES, 3“ voice coil
Nominal Impedance 4 Ohm
Input Connectors 2 x Neutrik NL4 Socket
parallel 1+/1-
Housing Birch Multiplex
Suspension/Mounting 35 mm pole socket
Coating anti-scratch
Polyurethane coating
Dimensions (h/w/d) 1160x494x457 mm
Net weight 57,0 kg

Picture Gallery

Accessories

Order Code GS1 (EAN) Code Description
HCS-215F-BAG 4260318511001 Nylon protection transport cover bag
KA-SP2-05 4260318510967 5 Meter Speaker cable 2x2,5qmm
KA-SP2-10 4260318510974 10 Meter Speaker cable 2x2,5qmm
KA-SP2-15 4260318510981 15 Meter Speaker cable 2x2,5qmm
KA-SP2-20 4260318510998 20 Meter Speaker cable 2x2,5qmm
SA-2130 4260318510844 2 Channel Class H Amplifier 2 x 1300 Watt @ 8 ohm
